Plug Valve

Rugged & Reliable On/Off Control for Abrasive & Viscous Media

Plug valves are quarter-turn rotary valves featuring a cylindrical or tapered plug with a through passage that aligns with the pipeline when open and blocks flow when rotated 90 degrees. Their simple, robust design ensures tight shut-off and excellent performance in slurries, viscous fluids, and abrasive services. Anante’s plug valves offer low torque operation, self-cleaning action, and minimal leakage. Available in lubricated and non-lubricated (sleeved) designs with full or reduced port options, they meet API 599 and API 6D standards. Ideal for oil & gas, petrochemical, pulp & paper, and mining applications, with options for fire-safe construction, jacketed bodies, and extended bonnets for extreme temperatures.

Forged Plug Valve

Robust Forged Plug Valves for High-Pressure Applications

Forged plug valves are designed for demanding environments, offering superior strength and resistance to high pressures and temperatures. Constructed through forging processes, they provide enhanced mechanical properties and are ideal for handling abrasive and corrosive fluids. With a simple quarter-turn operation, these valves ensure tight sealing, low torque, and reliable flow control in critical industrial settings.

Specification

  • Manufacturing Type: Forged
  • Size Range: 1/2" to 2"
  • Pressure Class: #2500
  • MOC: A105, F11, F22, LF2, F304, F304L, F316, F316L, F51, F53, F55, F347, F321, INCONEL 625, MONEL 400, HASTELLOY C-276, ALLOY 20
  • End Connections: Flange, Butweld, Socket Weld, Screwed
  • Operation: Manual, Actuated
  • Design Standard: API 599, API 6D, BS 5353, ISO 17292
  • Testing Standard: API 598, BSEN 12266-1
  • Certifications: PED, UKCA, TSG, TSSA, TR, ATEX, SIL, TA-Luft, API 6D, IBR
  • Seat Type: Soft (PTFE, NBR, Viton, EPDM, UHMWPE), Metal
  • Overlay Options: Alloy-6, Alloy-21, SS316, SS410, Monel, Inconel
  • Coatings: None

Feature

  • Quarter-turn rotary motion for quick operation
  • One-piece valve body with top loading design
  • Simple structure for convenient maintenance
  • Fire-safe to API standards
  • Anti-static design
  • Low operating torque
  • Fugitive emissions compliant
  • Actuator mounting flange according to ISO 5211

Benefit

  • Superior strength for high-pressure applications
  • Enhanced resistance to abrasion and corrosion
  • Long service life and reliability
  • Minimal leakage with tight sealing
  • Easy maintenance and low torque operation
  • Cost-effective for critical services

Applications

  • Oil & Gas
  • Petrochemical
  • Water
  • Chemical
  • Power
  • Food & Pharma

Cast Plug Valve

Versatile Cast Plug Valves for Medium-Pressure Systems

Cast plug valves are economical and reliable solutions for larger size applications in medium-pressure systems. Manufactured via casting, they offer good corrosion resistance and durability against thermal cycling. Suitable for a variety of fluids including gases, liquids, and slurries, these valves provide efficient on-off control with minimal maintenance in diverse industrial processes.

Specification

  • Manufacturing Type: Cast
  • Size Range: 2" to 12"
  • Pressure Class: #1500
  • MOC: WCB, WCC, LCA, LCB, LCC, WC1, WC6, WC9, C5, C12, CF8, CF3, CF8M, CF3M, CN7M, CF8C, CW6MC, CW2M, CY40, Cu5MCuC, 1A, 4A, 5A, 6A
  • End Connections: Flange, Butweld, Socket Weld, Screwed
  • Operation: Manual, Actuated
  • Design Standard: API 599, API 6D, BS 5353, ISO 17292
  • Testing Standard: API 598, BSEN 12266-1
  • Certifications: PED, UKCA, TSG, TSSA, TR, ATEX, SIL, TA-Luft, API 6D, IBR
  • Seat Type: Soft (PTFE, NBR, Viton, EPDM, UHMWPE), Metal
  • Overlay Options: Alloy-6, Alloy-21, SS316, SS410, Monel, Inconel
  • Coatings: FBE, ENP, Nylon

Feature

  • Quarter-turn rotary motion for quick operation
  • Robust construction resistant to thermal cycling
  • Simple structure for convenient maintenance
  • Fire-safe to API standards
  • Anti-static design
  • Low operating torque
  • Fugitive emissions compliant
  • Actuator mounting flange according to ISO 5211

Benefit

  • Economical for larger size applications
  • Good corrosion resistance
  • Long service life and reliability
  • Minimal leakage with tight sealing
  • Easy maintenance and low torque operation
  • Suitable for various fluids including slurries

Applications

  • Oil & Gas
  • Petrochemical
  • Water
  • Chemical
  • Power
  • Food & Pharma
